Spec/ Model |
ECO-BO-080-PP |
ECO-BO-120-PP |
ECO-BO-150-PP |
ECO-BO-180-PP |
Outer Dimensions
W x D x H |
800 x 680 x 1220 mm
31.5 x 26.7 x 48" |
1200 x 680 x 1220 mm
47.2 x 26.7 x 48" |
1500 x 680 x 1220 mm
59 x 26.7 x 48" |
1800 x 680 x 1220 mm
70.8 x 26.7 x 48" |
Workspace
(W x D x H) |
720 x 500 x 570 mm
28.3 x 19.6 x 22.4" |
1120 x 500 x 570 mm
44 x 19.7 x 22.4" |
1420 x 500 x 570 mm
55.9 x 19.7 x 22.4" |
1720 x 500 x 570 mm
67.7 x 19.7 x 22.4" |
Front Sash Max Opening |
400 mm / 15.7" |
400 mm / 15.7" |
400 mm / 15.7" |
400 mm / 15.7" |
Filter Type |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
Downflow Velocity |
0.33 m/s, 60 FPm |
0.33 m/s, 60 FPm |
0.33 m/s, 60 FPm |
0.33 m/s, 60 FPm |
Inflow velocity |
0.5 m/s, 100 fpm |
0.5 m/s, 100 fpm |
0.5 m/s, 100 fpm |
0.5 m/s, 100 fpm |
Airflow pattern |
70% circulation, 30% exhaust |
70% circulation, 30% exhaust |
70% circulation, 30% exhaust |
70% circulation, 30% exhaust |
Cleanliness level |
Class 100/ISO 5 |
Class 100/ISO 5 |
Class 100/ISO 5 |
Class 100/ISO 5 |
Cabinet Material |
Welded white polypropylene structure with stainless still 304 worktop |
Welded white polypropylene structure with stainless still 304 worktop |
Welded white polypropylene structure with stainless still 304 worktop |
Welded white polypropylene structure with stainless still 304 worktop |
Noise
(Tested 20 cm from worktable, 1.2m above ground) |
<52dB |
<52dB |
<52dB |
<52dB |
Power supply |
115 / 230V, 50/60 Hz, Single phase |
115 / 230V, 50/60 Hz, Single phase |
115 / 230V, 50/60 Hz, Single phase |
115 / 230V, 50/60 Hz, Single phase |
Illumination |
800 LUX, Eco-friendly LED lighting |
115 / 230V, 50/60 Hz, Single phase |
115 / 230V, 50/60 Hz, Single phase |
115 / 230V, 50/60 Hz, Single phase |
Filters |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
ULPA H15 Efficiency @99.9995% @ 0.1 um |
