| Spec/Model |
HC-V090-IVF |
HC-V120-IVF |
HC-V150-IVF |
HC-V180-IVF |
| Outer Dimensions W x D x H |
900 x 760 x 1250 mm
35.4 x 30 x 49.2" |
1200 x 760 x 1250 mm
47.2 x 30 x 49.2" |
1500 x 760 x 1250 mm
59 x 30 x 49.2" |
1800 x 760 x 1250 mm
70.8 x 30 x 49.2" |
| Workspace (W x D x H) |
770 x 660 x 750 mm
30.3 x 26 x 29.5" |
1070 x 660 x 750 mm
42.1 x 26 x 29.5" |
1370 x 660 x 750 mm
53.9 x 26 x 29.5" |
1670 x 660 x 750 mm
65.7 x 26 x 29.5" |
| Test Standard |
USA Federal Standard 209E / ISO-14644-1, CE |
USA Federal Standard 209E / ISO-14644-1, CE |
USA Federal Standard 209E / ISO-14644-1, CE |
USA Federal Standard 209E / ISO-14644-1, CE |
| Air Velocity m/s |
0.3 m/s, 60 FPM |
0.3 m/s, 60 FPM |
0.3 m/s, 60 FPM |
0.3 m/s, 60 FPM |
| Cleanliness in Workstation |
Class-100 (FS 209E) ISO 4, ISO-14644-1 |
Class-100 (FS 209E) ISO 4, ISO-14644-1 |
Class-100 (FS 209E) ISO 4, ISO-14644-1 |
Class-100 (FS 209E) ISO 4, ISO-14644-1 |
| Cabinet Material |
High grade cold rolled steel and surface is static powder coated |
High grade cold rolled steel and surface is static powder coated |
High grade cold rolled steel and surface is static powder coated |
High grade cold rolled steel and surface is static powder coated |
| Work Table Material |
Stainless steel SUS 304 |
Stainless steel SUS 304 |
Stainless steel SUS 304 |
Stainless steel SUS 304 |
| Noise (Tested 20 cm from the work table, 1.2m above ground |
<58dB |
<58dB |
<60dB |
<62dB |
| Power Supply |
110 / 220V, 50/60 Hz, Single phase |
110 / 220V, 50/60 Hz, Single phase |
110 / 220V 50/60 Hz, Single phase |
110 / 220V 50/60 Hz, Single phase |
| Illumination |
800 LUX LED lighting |
800 LUX LED lighting |
800 LUX LED lighting |
800 LUX LED lighting |
| Filter |
HEPA Filter Efficiency of 99,9995% at 0.3 Microns H14 (Optional ULPA filter) |
HEPA Filter Efficiency of 99,9995% at 0.3 Microns H14 (Optional ULPA filter) |
HEPA Filter Efficiency of 99,9995% at 0.3 Microns H14 (Optional ULPA filter) |
HEPA Filter Efficiency of 99,9995% at 0.3 Microns H14 (Optional ULPA filter) |
