Outer Dimensions
W x D x H |
600 x 750 x 1223
mm
23.62 x 29.5 x 48” |
900 x 750 x 1223
mm
35.4 x 29.5 x 48” |
1200 x 750 x 1223
mm mm
47.24 x 29.5 x 48” |
1500 x 750 x 1223 mm mm
59 x 29.5 x 48” |
1800 x 750 x 1223 mm mm
70.8 x 29.5 x 48” |
Dimensions for
XL model with 2
internal filters
W x D x H
For XL models
add –XL to P/N |
600 x 750 x 1323
mm
23.62 x 29.5 x 52" |
900 x 750 x 1323
mm
35.4 x 29.5 x 52" |
1200 x 750 x 1323
mm
47.24 x 29.5 x 52" |
1500 x 750 x 1323
mm
59 x 29.5 x 52" |
1800 x 750 x 1323
mm
70.8 x 29.5 x 52" |
Workspace
(W x D x H) |
585 x 590 x 695 mm
23 x 23.2 x 27.3" |
885 x 590 x 695 mm
34.8 x 23.2 x 27.3" |
1185 x 590 x 695 mm
46.6 x 23.2 x 27.3" |
1485 x 590 x 695 mm
58.4 x 23.2 x 27.3" |
1785 x 590 x 695 mm
70.2 x 23.2 x 27.3" |
Front Sash Opening |
495 mm / 19.5" |
495 mm / 19.5" |
495 mm / 19.5" |
495 mm / 19.5" |
495 mm / 19.5" |
Test Standard |
EN-14175 / CE / ASHRAE 110-1995 |
EN-14175 / CE / ASHRAE 110-1995 |
EN-14175 / CE / ASHRAE 110-1995 |
EN-14175 / CE / ASHRAE 110-1995 |
EN-14175 / CE / ASHRAE 110-1995 |
Air Velocity |
0.5±0.1 m/s, 100±20 FPM |
0.5±0.1 m/s, 100±20 FPM |
0.5±0.1 m/s, 100±20 FPM |
0.5±0.1 m/s, 100±20 FPM |
0.5±0.1 m/s, 100±20 FPM |
Cabinet Material |
Welded white polypropylene structure with built-in sealed polypropylene worktop |
Welded white polypropylene structure with built-in sealed polypropylene worktop |
Welded white polypropylene structure with built-in sealed polypropylene worktop |
Welded white polypropylene structure with built-in sealed polypropylene worktop |
Welded white polypropylene structure with built-in sealed polypropylene worktop |
Noise
(Tested 20 cm from the work table, 1.2m above ground) |
<52dB |
<52dB |
<54dB |
<60dB |
<62dB |
Power Supply |
110 / 220V 50/60 Hz, Single phase |
110 / 220V 50/60 Hz, Single phase |
110 / 220V 50/60 Hz, Single phase |
110 / 220V 50/60 Hz, Single phase |
110 / 220V 50/60 Hz, Single phase |
Illumination |
800 LUX, Eco-friendly LED lighting |
800 LUX, Eco-friendly LED lighting |
800 LUX, Eco-friendly LED lighting |
800 LUX, Eco-friendly LED lighting |
800 LUX, Eco-friendly LED lighting |
Filter |
Carbon filters for solvents, acids, bases, formaldehyde, multi gas (blend of materials) /HEPA/ULPA |
Carbon filters for solvents, acids, bases, formaldehyde, multi gas (blend of materials) /HEPA/ULPA |
Carbon filters for solvents, acids, bases, formaldehyde, multi gas (blend of materials) /HEPA/ULPA |
Carbon filters for solvents, acids, bases, formaldehyde, multi gas (blend of materials) /HEPA/ULPA |
Carbon filters for solvents, acids, bases, formaldehyde, multi gas (blend of materials) /HEPA/ULPA |
